适用于工业领域中干燥或潮湿环境下室内的电气连接，在有中等负载或是偶尔往复移动的弯曲场合进行敷设，在某些要求不苛刻的拖链环境或者扭转情形中也可应用。该产品广泛应用于工业自动化设备、测控设备、加热设备、制冷设备、运输行业、化工行业、冶金行业、新能源等。若对抗电磁干扰有要求可选用FIC 120 CY。
· 细裸铜丝绞合，符合IEC 60228 5类标准
· 线芯绝缘：改性聚氯乙烯混合物
· 线芯颜色：符合VDE 0293-1
· 线芯层绞成缆
· 外护套：改性聚氯乙烯混合物，灰色 RAL 7001
· 阻燃特性符合IEC 60332-1-2
· 耐化学试剂
· 轻度耐油
· 耐扭转
· 200万次弯曲循环，拖链行程5m
参考VDE 0245，0281，0293，0295设计
| 型号规格 | 芯数×标称截面mm² | 标称外径mm | 标称铜重kg/km | 标称电缆重量kg/km |
| FIC 120 2 X 0.5 | 2 X 0.5 | 4.9 | 9.6 | 35.4 |
| FIC 120 3 G 0.5 | 3 G 0.5 | 5.3 | 14.4 | 42.4 |
| FIC 120 3 X 0.5 | 3 X 0.5 | 5.3 | 14.4 | 42.4 |
| FIC 120 4 G 0.5 | 4 G 0.5 | 5.9 | 19.2 | 54.5 |
| FIC 120 4 X 0.5 | 4 X 0.5 | 5.9 | 19.2 | 54.5 |
| FIC 120 5 G 0.5 | 5 G 0.5 | 6.4 | 24.0 | 63.6 |
| FIC 120 5 X 0.5 | 5 X 0.5 | 6.4 | 24.0 | 63.6 |
| FIC 120 7 G 0.5 | 7 G 0.5 | 6.9 | 33.6 | 81.8 |
| FIC 120 7 X 0.5 | 7 X 0.5 | 6.9 | 33.6 | 81.8 |
| FIC 120 10 G 0.5 | 10 G 0.5 | 8.9 | 48.0 | 117.2 |
| FIC 120 12 G 0.5 | 12 G 0.5 | 9.2 | 58.0 | 132.3 |
| FIC 120 14 G 0.5 | 14 G 0.5 | 9.8 | 67.0 | 154.5 |
| FIC 120 18 G 0.5 | 18 G 0.5 | 10.8 | 86.4 | 189.9 |
| FIC 120 21 G 0.5 | 21 G 0.5 | 12.1 | 101.0 | 223.2 |
| FIC 120 25 G 0.5 | 25 G 0.5 | 12.8 | 120.0 | 263.6 |
| FIC 120 30 G 0.5 | 30 G 0.5 | 13.7 | 144.0 | 307.0 |
| FIC 120 35 G 0.5 | 35 G 0.5 | 14.9 | 168.0 | 359.6 |
| FIC 120 40 G 0.5 | 40 G 0.5 | 15.9 | 192.0 | 404.0 |
| FIC 120 52 G 0.5 | 52 G 0.5 | 17.8 | 250.0 | 522.2 |
| FIC 120 61 G 0.5 | 61 G 0.5 | 19.1 | 293.0 | 609.0 |
| FIC 120 65 G 0.5 | 65 G 0.5 | 20.2 | 312.0 | 650.4 |
| FIC 120 80 G 0.5 | 80 G 0.5 | 21.7 | 384.0 | 787.8 |
| FIC 120 100 G 0.5 | 100 G 0.5 | 24.3 | 480.0 | 984.8 |
| FIC 120 2 X 0.75 | 2 X 0.75 | 5.6 | 14.4 | 45.5 |
| FIC 120 3 G 0.75 | 3 G 0.75 | 5.9 | 21.6 | 55.6 |
| FIC 120 3 X 0.75 | 3 X 0.75 | 5.9 | 21.6 | 55.6 |
| FIC 120 4 G 0.75 | 4 G 0.75 | 6.4 | 28.8 | 66.7 |
| FIC 120 4 X 0.75 | 4 X 0.75 | 6.4 | 28.8 | 66.7 |
| FIC 120 5 G 0.75 | 5 G 0.75 | 6.9 | 36.0 | 79.8 |
| FIC 120 5 X 0.75 | 5 X 0.75 | 6.9 | 36.0 | 79.8 |
| FIC 120 7 G 0.75 | 7 G 0.75 | 7.5 | 50.0 | 102.0 |
| FIC 120 7 X 0.75 | 7 X 0.75 | 7.5 | 50.0 | 102.0 |
| FIC 120 9 G 0.75 | 9 G 0.75 | 9.7 | 65.0 | 138.4 |
| FIC 120 10 G 0.75 | 10 G 0.75 | 9.9 | 72.0 | 151.5 |
| FIC 120 12 G 0.75 | 12 G 0.75 | 10.2 | 86.0 | 172.7 |
| FIC 120 12 X 0.75 | 12 X 0.75 | 10.2 | 86.0 | 172.7 |
| FIC 120 15 G 0.75 | 15 G 0.75 | 11.2 | 108.0 | 211.1 |
| FIC 120 15 X 0.75 | 15 X 0.75 | 11.2 | 108.0 | 211.1 |
| FIC 120 16 G 0.75 | 16 G 0.75 | 11.4 | 115.2 | 222.2 |
| FIC 120 18 G 0.75 | 18 G 0.75 | 12.1 | 130.0 | 246.4 |
| FIC 120 21 G 0.75 | 21 G 0.75 | 13.4 | 151.0 | 288.9 |
| FIC 120 25 G 0.75 | 25 G 0.75 | 14.2 | 180.0 | 340.4 |
| FIC 120 26 G 0.75 | 26 G 0.75 | 14.6 | 187.2 | 353.5 |
| FIC 120 34 G 0.75 | 34 G 0.75 | 16.4 | 245.0 | 452.5 |
| FIC 120 41 G 0.75 | 41 G 0.75 | 17.9 | 296.0 | 543.4 |
| FIC 120 50 G 0.75 | 50 G 0.75 | 19.8 | 360.0 | 654.5 |
| FIC 120 51 G 0.75 | 51 G 0.75 | 19.8 | 367.0 | 652.5 |
| FIC 120 61 G 0.75 | 61 G 0.75 | 21.1 | 439.0 | 786.8 |
| FIC 120 65 G 0.75 | 65 G 0.75 | 22.5 | 468.0 | 840.3 |
| FIC 120 80 G 0.75 | 80 G 0.75 | 24.3 | 576.0 | 1029.2 |
| FIC 120 100 G 0.75 | 100 G 0.75 | 27.2 | 718.0 | 1283.7 |
| FIC 120 2 X 1 | 2 X 1 | 5.9 | 19.2 | 53.5 |
| FIC 120 3 G 1 | 3 G 1 | 6.2 | 28.8 | 65.7 |
| FIC 120 3 X 1 | 3 X 1 | 6.2 | 28.8 | 65.7 |
| FIC 120 4 G 1 | 4 G 1 | 6.7 | 38.4 | 79.8 |
| FIC 120 4 X 1 | 4 X 1 | 6.7 | 38.4 | 79.8 |
| FIC 120 5 G 1 | 5 G 1 | 7.3 | 48.0 | 94.9 |
| FIC 120 5 X 1 | 5 X 1 | 7.3 | 48.0 | 94.9 |
| FIC 120 6 G 1 | 6 G 1 | 8.2 | 58.0 | 114.1 |
| FIC 120 7 G 1 | 7 G 1 | 8.2 | 67.0 | 127.3 |
| FIC 120 7 X 1 | 7 X 1 | 8.2 | 67.0 | 127.3 |
| FIC 120 8 G 1 | 8 G 1 | 9.8 | 77.0 | 150.5 |
| FIC 120 9 G 1 | 9 G 1 | 10.3 | 86.0 | 165.6 |
| FIC 120 10 G 1 | 10 G 1 | 10.5 | 96.0 | 181.8 |
| FIC 120 12 G 1 | 12 G 1 | 10.8 | 115.0 | 207.1 |
| FIC 120 12 X 1 | 12 X 1 | 10.8 | 115.0 | 207.1 |
| FIC 120 14 G 1 | 14 G 1 | 11.5 | 134.0 | 240.4 |
| FIC 120 16 G 1 | 16 G 1 | 12.2 | 153.6 | 268.7 |
| FIC 120 18 G 1 | 18 G 1 | 13.1 | 173.0 | 323.2 |
| FIC 120 18 X 1 | 18 X 1 | 13.1 | 173.0 | 323.2 |
| FIC 120 20 G 1 | 20 G 1 | 13.8 | 192.0 | 333.3 |
| FIC 120 20 X 1 | 20 X 1 | 13.8 | 192.0 | 333.3 |
| FIC 120 25 G 1 | 25 G 1 | 15.1 | 240.0 | 412.1 |
| FIC 120 26 G 1 | 26 G 1 | 15.6 | 249.0 | 428.2 |
| FIC 120 34 G 1 | 34 G 1 | 17.6 | 326.0 | 556.5 |
| FIC 120 36 G 1 | 36 G 1 | 17.9 | 346.0 | 583.8 |
| FIC 120 41 G 1 | 41 G 1 | 19.4 | 394.0 | 667.6 |
| FIC 120 50 G 1 | 50 G 1 | 21.2 | 480.0 | 805.0 |
| FIC 120 56 G 1 | 56 G 1 | 22.0 | 538.0 | 896.9 |
| FIC 120 61 G 1 | 61 G 1 | 22.8 | 586.0 | 967.6 |
| FIC 120 65 G 1 | 65 G 1 | 24.3 | 624.0 | 1043.3 |
| FIC 120 80 G 1 | 80 G 1 | 26.1 | 768.0 | 1263.5 |
| FIC 120 100 G 1 | 100 G 1 | 29.1 | 960.0 | 1575.6 |
| FIC 120 2 X 1.5 | 2 X 1.5 | 6.5 | 29.0 | 68.7 |
| FIC 120 3 G 1.5 | 3 G 1.5 | 6.9 | 43.0 | 84.8 |
| FIC 120 3 X 1.5 | 3 X 1.5 | 6.9 | 43.0 | 84.8 |
| FIC 120 4 G 1.5 | 4 G 1.5 | 7.4 | 58.0 | 105.0 |
| FIC 120 4 X 1.5 | 4 X 1.5 | 7.4 | 58.0 | 105.0 |
| FIC 120 5 G 1.5 | 5 G 1.5 | 8.3 | 72.0 | 129.3 |
| FIC 120 5 X 1.5 | 5 X 1.5 | 8.3 | 72.0 | 129.3 |
| FIC 120 6 G 1.5 | 6 G 1.5 | 8.7 | 86.4 | 158.6 |
| FIC 120 7 G 1.5 | 7 G 1.5 | 9.2 | 101.0 | 167.7 |
| FIC 120 7 X 1.5 | 7 X 1.5 | 9.2 | 101.0 | 167.7 |
| FIC 120 8 G 1.5 | 8 G 1.5 | 10.9 | 115.0 | 212.1 |
| FIC 120 8 X 1.5 | 8 X 1.5 | 10.9 | 116.0 | 212.1 |
| FIC 120 9 G 1.5 | 9 G 1.5 | 11.7 | 130.0 | 223.2 |
| FIC 120 10 G 1.5 | 10 G 1.5 | 11.9 | 143.0 | 245.4 |
| FIC 120 11 G 1.5 | 11 G 1.5 | 11.9 | 158.0 | 260.6 |
| FIC 120 12 G 1.5 | 12 G 1.5 | 12.4 | 173.0 | 281.8 |
| FIC 120 12 X 1.5 | 12 X 1.5 | 12.4 | 173.0 | 281.8 |
| FIC 120 14 G 1.5 | 14 G 1.5 | 13.1 | 202.0 | 326.2 |
| FIC 120 16 G 1.5 | 16 G 1.5 | 13.8 | 230.4 | 364.6 |
| FIC 120 18 G 1.5 | 18 G 1.5 | 14.8 | 259.0 | 411.1 |
| FIC 120 21 G 1.5 | 21 G 1.5 | 16.2 | 302.0 | 473.7 |
| FIC 120 25 G 1.5 | 25 G 1.5 | 17.4 | 360.0 | 565.6 |
| FIC 120 26 G 1.5 | 26 G 1.5 | 17.8 | 374.4 | 587.8 |
| FIC 120 32 G 1.5 | 32 G 1.5 | 19.3 | 461.0 | 711.0 |
| FIC 120 34 G 1.5 | 34 G 1.5 | 20.0 | 490.0 | 753.5 |
| FIC 120 41 G 1.5 | 41 G 1.5 | 21.9 | 591.0 | 904.0 |
| FIC 120 50 G 1.5 | 50 G 1.5 | 24.2 | 720.0 | 1099.9 |
| FIC 120 61 G 1.5 | 61 G 1.5 | 26.0 | 878.0 | 1322.1 |
| FIC 120 65 G 1.5 | 65 G 1.5 | 27.5 | 936.0 | 1412.0 |
| FIC 120 2 X 2.5 | 2 X 2.5 | 7.7 | 48.0 | 102.0 |
| FIC 120 3 G 2.5 | 3 G 2.5 | 8.3 | 72.0 | 133.3 |
| FIC 120 4 G 2.5 | 4 G 2.5 | 9.2 | 96.0 | 164.6 |
| FIC 120 5 G 2.5 | 5 G 2.5 | 10.3 | 120.0 | 202.0 |
| FIC 120 7 G 2.5 | 7 G 2.5 | 11.4 | 168.0 | 269.7 |
| FIC 120 12 G 2.5 | 12 G 2.5 | 15.2 | 288.0 | 449.5 |
| FIC 120 14 G 2.5 | 14 G 2.5 | 16.3 | 336.0 | 520.2 |
| FIC 120 18 G 2.5 | 18 G 2.5 | 18.3 | 432.0 | 654.5 |
| FIC 120 25 G 2.5 | 25 G 2.5 | 21.4 | 600.0 | 898.9 |
| FIC 120 34 G 2.5 | 34 G 2.5 | 25.1 | 816.0 | 1220.1 |
| FIC 120 50 G 2.5 | 50 G 2.5 | 30.3 | 1200.0 | 1771.5 |
| FIC 120 3 G 4 | 3 G 4 | 10.2 | 115.0 | 203.0 |
| FIC 120 4 G 4 | 4 G 4 | 11.1 | 154.0 | 251.5 |
| FIC 120 5 G 4 | 5 G 4 | 12.5 | 192.0 | 296.9 |
| FIC 120 7 G 4 | 7 G 4 | 13.8 | 269.0 | 411.1 |
| FIC 120 11 G 4 | 11 G 4 | 18.1 | 422.0 | 640.3 |
| FIC 120 12 G 4 | 12 G 4 | 18.6 | 461.0 | 666.6 |
| FIC 120 3 G 6 | 3 G 6 | 12.1 | 172.8 | 291.9 |
| FIC 120 4 G 6 | 4 G 6 | 13.4 | 230.0 | 368.7 |
| FIC 120 5 G 6 | 5 G 6 | 14.9 | 288.0 | 451.5 |
| FIC 120 7 G 6 | 7 G 6 | 16.5 | 403.0 | 606.0 |
| FIC 120 3 G 10 | 3 G 10 | 15.0 | 288.0 | 470.7 |
| FIC 120 4 G 10 | 4 G 10 | 16.7 | 384.0 | 595.9 |
| FIC 120 5 G 10 | 5 G 10 | 18.6 | 480.0 | 729.2 |
| FIC 120 7 G 10 | 7 G 10 | 20.6 | 672.0 | 977.7 |
| FIC 120 4 G 16 | 4 G 16 | 19.4 | 614.0 | 1097.9 |
| FIC 120 5 G 16 | 5 G 16 | 21.8 | 768.0 | 1383.7 |
| FIC 120 7 G 16 | 7 G 16 | 24.1 | 1075.0 | 1796.8 |
| FIC 120 4 G 25 | 4 G 25 | 24.2 | 960.0 | 1597.8 |
| FIC 120 5 G 25 | 5 G 25 | 27.2 | 1200.0 | 2018.0 |
| FIC 120 7 G 25 | 7 G 25 | 30.0 | 1680.0 | 2853.3 |
| FIC 120 4 G 35 | 4 G 35 | 27.2 | 1344.0 | 2127.1 |
| FIC 120 5 G 35 | 5 G 35 | 30.5 | 1680.0 | 2661.4 |
