应用于工业自动化、机电成套设备、自动物流系统、装配线、传感系统、控制设备和控制工程等领域需要以一定速度频繁移动的机械部件或动力拖链系统，作控制电缆使用，用于测量、控制和电路调配。适用于室内或室外干燥或潮湿的区域。特殊结构设计和先进材料的应用，确保电缆具备长使用寿命及高稳定性。若对抗电磁干扰有要求可选用FIDC 660 CY，对耐磨耐油有要求可选用FIDC 660 P。
· 超细裸铜丝绞合，符合IEC 60228 6类标准
· 线芯绝缘：改性聚氯乙烯混合物
· 线芯颜色：符合VDE 0293-1
· 线芯依照独特的节距控制方案绞合成缆，无纺布绕包
· 外护套：改性聚氯乙烯混合物，灰色 RAL 7001
· 阻燃特性符合IEC 60332-1-2
· 耐化学试剂
· 抗UV
· 500万次弯曲循环，拖链行程10m
| 型号规格 | 芯数×标称截面mm² | 标称外径 mm | 标称铜重 kg/km | 标称电缆重量kg/km |
| FIDC 660 2 X 0.5 | 2 X 0.5 | 5.5 | 10.0 | 40.4 |
| FIDC 660 3 G 0.5 | 3 G 0.5 | 5.9 | 15.0 | 48.5 |
| FIDC 660 4 G 0.5 | 4 G 0.5 | 6.5 | 19.2 | 58.6 |
| FIDC 660 5 G 0.5 | 5 G 0.5 | 7.0 | 24.0 | 67.7 |
| FIDC 660 7 G 0.5 | 7 G 0.5 | 8.2 | 34.0 | 88.9 |
| FIDC 660 12 G 0.5 | 12 G 0.5 | 9.8 | 58.0 | 137.4 |
| FIDC 660 18 G 0.5 | 18 G 0.5 | 11.7 | 86.4 | 197.0 |
| FIDC 660 25 G 0.5 | 25 G 0.5 | 14.1 | 120.0 | 276.7 |
| FIDC 660 30 G 0.5 | 30 G 0.5 | 14.7 | 144.0 | 315.1 |
| FIDC 660 34 G 0.5 | 34 G 0.5 | 16.1 | 164.0 | 362.6 |
| FIDC 660 50 G 0.5 | 50 G 0.5 | 19.1 | 240.0 | 520.2 |
| FIDC 660 2 X 0.75 | 2 X 0.75 | 5.9 | 15.0 | 49.5 |
| FIDC 660 3 G 0.75 | 3 G 0.75 | 6.4 | 22.0 | 60.6 |
| FIDC 660 4 G 0.75 | 4 G 0.75 | 7.0 | 29.0 | 73.7 |
| FIDC 660 5 G 0.75 | 5 G 0.75 | 7.6 | 37.0 | 86.9 |
| FIDC 660 7 G 0.75 | 7 G 0.75 | 9.2 | 51.0 | 118.2 |
| FIDC 660 12 G 0.75 | 12 G 0.75 | 10.9 | 87.0 | 182.8 |
| FIDC 660 16 G 0.75 | 16 G 0.75 | 12.4 | 116.0 | 236.3 |
| FIDC 660 18 G 0.75 | 18 G 0.75 | 13.1 | 130.0 | 261.6 |
| FIDC 660 25 G 0.75 | 25 G 0.75 | 15.7 | 181.0 | 366.6 |
| FIDC 660 2 X 1 | 2 X 1 | 6.3 | 19.0 | 58.6 |
| FIDC 660 3 G 1 | 3 G 1 | 6.8 | 29.0 | 72.7 |
| FIDC 660 4 G 1 | 4 G 1 | 7.5 | 39.0 | 88.9 |
| FIDC 660 5 G 1 | 5 G 1 | 8.2 | 48.0 | 105.0 |
| FIDC 660 7 G 1 | 7 G 1 | 9.9 | 67.0 | 143.4 |
| FIDC 660 12 G 1 | 12 G 1 | 11.7 | 115.0 | 223.2 |
| FIDC 660 14 G 1 | 14 G 1 | 12.7 | 134.4 | 260.6 |
| FIDC 660 16 G 1 | 16 G 1 | 13.4 | 153.0 | 289.9 |
| FIDC 660 18 G 1 | 18 G 1 | 14.3 | 173.0 | 327.2 |
| FIDC 660 25 G 1 | 25 G 1 | 16.9 | 240.0 | 449.5 |
| FIDC 660 26 G 1 | 26 G 1 | 16.9 | 249.6 | 463.6 |
| FIDC 660 34 G 1 | 34 G 1 | 19.5 | 326.4 | 601.0 |
| FIDC 660 41 G 1 | 41 G 1 | 21.2 | 394.0 | 719.1 |
| FIDC 660 50 G 1 | 50 G 1 | 23.0 | 480.0 | 862.5 |
| FIDC 660 65 G 1 | 65 G 1 | 26.2 | 624.0 | 1108.0 |
| FIDC 660 2 X 1.5 | 2 X 1.5 | 7.0 | 29.0 | 74.7 |
| FIDC 660 3 G 1.5 | 3 G 1.5 | 7.6 | 43.2 | 93.9 |
| FIDC 660 4 G 1.5 | 4 G 1.5 | 8.3 | 58.0 | 115.1 |
| FIDC 660 5 G 1.5 | 5 G 1.5 | 9.4 | 72.0 | 140.4 |
| FIDC 660 7 G 1.5 | 7 G 1.5 | 11.2 | 101.0 | 190.9 |
| FIDC 660 12 G 1.5 | 12 G 1.5 | 13.3 | 173.0 | 298.0 |
| FIDC 660 18 G 1.5 | 18 G 1.5 | 16.1 | 259.0 | 433.3 |
| FIDC 660 25 G 1.5 | 25 G 1.5 | 19.2 | 360.0 | 603.0 |
| FIDC 660 26 G 1.5 | 26 G 1.5 | 19.2 | 374.4 | 621.2 |
| FIDC 660 34 G 1.5 | 34 G 1.5 | 21.7 | 489.6 | 790.8 |
| FIDC 660 41 G 1.5 | 41 G 1.5 | 23.7 | 613.0 | 945.4 |
| FIDC 660 42 G 1.5 | 42 G 1.5 | 23.7 | 629.0 | 963.5 |
| FIDC 660 50 G 1.5 | 50 G 1.5 | 25.8 | 720.0 | 1145.3 |
| FIDC 660 3 G 2.5 | 3 G 2.5 | 9.3 | 72.0 | 146.5 |
| FIDC 660 4 G 2.5 | 4 G 2.5 | 10.3 | 96.0 | 180.8 |
| FIDC 660 5 G 2.5 | 5 G 2.5 | 11.5 | 120.0 | 220.2 |
| FIDC 660 7 G 2.5 | 7 G 2.5 | 14.0 | 168.0 | 306.0 |
| FIDC 660 12 G 2.5 | 12 G 2.5 | 16.5 | 288.0 | 477.7 |
| FIDC 660 14 G 2.5 | 14 G 2.5 | 17.7 | 336.0 | 553.5 |
| FIDC 660 3 G 4 | 3 G 4 | 10.9 | 120.0 | 216.1 |
| FIDC 660 4 G 4 | 4 G 4 | 12.1 | 160.0 | 268.7 |
| FIDC 660 5 G 4 | 5 G 4 | 13.5 | 200.0 | 328.3 |
| FIDC 660 4 G 6 | 4 G 6 | 14.3 | 230.4 | 400.0 |
| FIDC 660 5 G 6 | 5 G 6 | 16.0 | 288.0 | 488.8 |
| FIDC 660 4 G 10 | 4 G 10 | 18.1 | 384.0 | 650.4 |
| FIDC 660 5 G 10 | 5 G 10 | 20.2 | 480.0 | 792.9 |
| FIDC 660 4 G 16 | 4 G 16 | 21.6 | 615.0 | 931.2 |
| FIDC 660 5 G 16 | 5 G 16 | 24.3 | 768.0 | 1144.3 |
