应用于机器、机械加工、装配生产线、机床、输送产线、传感系统、控制设备和控制工程等领域中的拖链系统或可自由移动的机器部件，作控制电缆使用，用于电路系统的测控与调节。选用先进材料，电缆具有较高的柔性以及耐磨性等特性，适用于存在有害矿物质油类以及耐化学试剂和机械性能要求较高的场景。若对抗电磁干扰有要求可选用FIDC 660 CP，超长行程拖链（≥100m）可选用FIDC 680 P。
· 超细裸铜丝绞合，符合IEC 60228 6类标准
· 线芯绝缘：改性聚氯乙烯混合物
· 线芯颜色：符合VDE 0293-1
· 线芯绞合成缆，无纺布绕包
· 外护套：改性聚氨酯混合物，灰色 RAL 7001
· 阻燃特性符合IEC 60332-1-2
· 高度耐油
· 耐化学试剂
· 抗UV
· 耐摩擦、撕裂及冲击性性能良好
· 500万次弯曲循环，拖链行程10m
| 型号规格 | 芯数×标称截面mm² | 标称外径 mm | 标称铜重 kg/km | 标称电缆重量kg/km |
| FIDC 660 P 2 X 0.5 | 2 X 0.5 | 5.5 | 10.0 | 36.4 |
| FIDC 660 P 3 G 0.5 | 3 G 0.5 | 5.9 | 15.0 | 44.4 |
| FIDC 660 P 4 G 0.5 | 4 G 0.5 | 6.5 | 19.0 | 53.5 |
| FIDC 660 P 5 G 0.5 | 5 G 0.5 | 7.0 | 24.0 | 62.6 |
| FIDC 660 P 7 G 0.5 | 7 G 0.5 | 8.2 | 34.0 | 82.8 |
| FIDC 660 P 12 G 0.5 | 12 G 0.5 | 9.8 | 58.0 | 130.3 |
| FIDC 660 P 18 G 0.5 | 18 G 0.5 | 11.7 | 86.4 | 186.9 |
| FIDC 660 P 2 X 0.75 | 2 X 0.75 | 5.9 | 15.0 | 44.4 |
| FIDC 660 P 3 G 0.75 | 3 G 0.75 | 6.4 | 22.0 | 55.6 |
| FIDC 660 P 4 G 0.75 | 4 G 0.75 | 7.0 | 29.0 | 67.7 |
| FIDC 660 P 5 G 0.75 | 5 G 0.75 | 7.6 | 37.0 | 80.8 |
| FIDC 660 P 7 G 0.75 | 7 G 0.75 | 9.2 | 51.0 | 110.1 |
| FIDC 660 P 12 G 0.75 | 12 G 0.75 | 10.9 | 87.0 | 173.7 |
| FIDC 660 P 18 G 0.75 | 18 G 0.75 | 13.1 | 130.0 | 249.5 |
| FIDC 660 P 25 G 0.75 | 25 G 0.75 | 15.7 | 181.0 | 349.5 |
| FIDC 660 P 2 X 1 | 2 X 1 | 6.3 | 20.0 | 52.5 |
| FIDC 660 P 3 G 1 | 3 G 1 | 6.8 | 29.0 | 66.7 |
| FIDC 660 P 4 G 1 | 4 G 1 | 7.5 | 39.0 | 82.8 |
| FIDC 660 P 5 G 1 | 5 G 1 | 8.2 | 48.0 | 98.0 |
| FIDC 660 P 7 G 1 | 7 G 1 | 9.9 | 67.0 | 118.2 |
| FIDC 660 P 12 G 1 | 12 G 1 | 11.7 | 115.0 | 213.1 |
| FIDC 660 P 18 G 1 | 18 G 1 | 14.3 | 173.0 | 313.1 |
| FIDC 660 P 25 G 1 | 25 G 1 | 16.9 | 240.0 | 430.3 |
| FIDC 660 P 34 G 1 | 34 G 1 | 19.5 | 326.4 | 576.7 |
| FIDC 660 P 41 G 1 | 41 G 1 | 21.2 | 394.0 | 690.8 |
| FIDC 660 P 50 G 1 | 50 G 1 | 23.0 | 480.0 | 830.2 |
| FIDC 660 P 65 G 1 | 65 G 1 | 26.2 | 624.0 | 1068.6 |
| FIDC 660 P 2 X 1.5 | 2 X 1.5 | 7.0 | 29.0 | 68.7 |
| FIDC 660 P 3 G 1.5 | 3 G 1.5 | 7.6 | 43.2 | 86.9 |
| FIDC 660 P 4 G 1.5 | 4 G 1.5 | 8.3 | 58.0 | 107.1 |
| FIDC 660 P 5 G 1.5 | 5 G 1.5 | 9.4 | 72.0 | 132.3 |
| FIDC 660 P 7 G 1.5 | 7 G 1.5 | 11.2 | 101.0 | 179.8 |
| FIDC 660 P 12 G 1.5 | 12 G 1.5 | 13.3 | 173.0 | 283.8 |
| FIDC 660 P 16 G 1.5 | 16 G 1.5 | 15.0 | 230.0 | 368.7 |
| FIDC 660 P 18 G 1.5 | 18 G 1.5 | 16.1 | 259.0 | 415.1 |
| FIDC 660 P 25 G 1.5 | 25 G 1.5 | 19.2 | 360.0 | 576.7 |
| FIDC 660 P 34 G 1.5 | 34 G 1.5 | 21.7 | 489.6 | 760.5 |
| FIDC 660 P 42 G 1.5 | 42 G 1.5 | 23.7 | 629.0 | 928.2 |
| FIDC 660 P 50 G 1.5 | 50 G 1.5 | 25.8 | 720.0 | 1103.9 |
| FIDC 660 P 3 G 2.5 | 3 G 2.5 | 9.3 | 72.0 | 136.4 |
| FIDC 660 P 4 G 2.5 | 4 G 2.5 | 10.3 | 96.0 | 169.7 |
| FIDC 660 P 5 G 2.5 | 5 G 2.5 | 11.5 | 120.0 | 208.1 |
| FIDC 660 P 7 G 2.5 | 7 G 2.5 | 14.0 | 168.0 | 288.9 |
| FIDC 660 P 12 G 2.5 | 12 G 2.5 | 16.5 | 288.0 | 457.5 |
| FIDC 660 P 14 G 2.5 | 14 G 2.5 | 17.7 | 336.0 | 530.3 |
| FIDC 660 P 4 G 4 | 4 G 4 | 12.1 | 160.0 | 254.5 |
| FIDC 660 P 5 G 4 | 5 G 4 | 13.5 | 200.0 | 312.1 |
| FIDC 660 P 1 G 6 | 1 G 6 | 6.6 | 60.0 | 84.8 |
| FIDC 660 P 4 G 6 | 4 G 6 | 14.3 | 230.0 | 380.8 |
| FIDC 660 P 1 G 10 | 1 G 10 | 7.9 | 100.0 | 142.4 |
| FIDC 660 P 4 G 10 | 4 G 10 | 18.1 | 384.0 | 620.1 |
| FIDC 660 P 5 G 10 | 5 G 10 | 20.2 | 480.0 | 758.5 |
| FIDC 660 P 1 G 16 | 1 G 16 | 9.5 | 160.0 | 200.0 |
| FIDC 660 P 4 G 16 | 4 G 16 | 21.6 | 615.0 | 859.5 |
