适用于工业领域中干燥或潮湿环境下室内或室外的电气连接，该电缆在有潜在火灾危险的区域或设备、重要资产集中以及人口密度较大的区域尤其适用。产品广泛应用于工业自动化设备、测控设备、加热设备、制冷设备、运输行业、化工行业、冶金行业、新能源等。该产品选用特殊无卤混合物材料，并结合独特结构设计，产品极其柔软，便于安装和使用。
• 细裸铜丝绞合，符合IEC 60228 5类标准
• 线芯绝缘：改性无卤混合物
• 线芯颜色符合VDE 0293-1
• 线芯层绞成缆
• 外护套：改性无卤混合物，灰色RAL 7001
• 阻燃特性符合IEC 60332-1-2
• 无卤特性符合IEC 60754-1
• 燃烧气体腐蚀特性符合IEC 60754-2
• 烟密度符合IEC 61034-2
• 耐化学试剂
• 轻度耐油，符合EN 50290-2-22（TM54）
• 抗UV和耐候性符合ISO 4892-2
• 耐臭氧符合EN 50396
参考EN 50525-3-11
| 型号规格 | 芯数×标称截面mm² | 外径mm | 铜重kg/km | 电缆重量kg/km |
| FIC 120 H 2×0.5 | 2×0.5 | 5.1 | 9.6 | 41 |
| FIC 120 H 3G0.5 | 3G0.5 | 5.4 | 14.4 | 49 |
| FIC 120 H 3×0.5 | 3×0.5 | 5.4 | 14.4 | 49 |
| FIC 120 H 4G0.5 | 4G0.5 | 5.8 | 19.2 | 58 |
| FIC 120 H 4×0.5 | 4×0.5 | 5.8 | 19.2 | 58 |
| FIC 120 H 5G0.5 | 5G0.5 | 6.3 | 24 | 69 |
| FIC 120 H 7G0.5 | 7G0.5 | 6.9 | 33.6 | 87 |
| FIC 120 H 12G0.5 | 12G0.5 | 9.1 | 57.6 | 141 |
| FIC 120 H 2×0.75 | 2×0.75 | 5.5 | 14.4 | 51 |
| FIC 120 H 3G0.75 | 3G0.75 | 5.8 | 21.6 | 61 |
| FIC 120 H 3×0.75 | 3×0.75 | 5.8 | 21.6 | 61 |
| FIC 120 H 4G0.75 | 4G0.75 | 6.3 | 28.8 | 73 |
| FIC 120 H 4×0.75 | 4×0.75 | 6.3 | 28.8 | 73 |
| FIC 120 H 5G0.75 | 5G0.75 | 6.9 | 36 | 87 |
| FIC 120 H 5×0.75 | 5×0.75 | 6.9 | 36 | 87 |
| FIC 120 H 7G0.75 | 7G0.75 | 7.5 | 50.4 | 111 |
| FIC 120 H 7×0.75 | 7×0.75 | 7.5 | 50.4 | 111 |
| FIC 120 H 9G0.75 | 9G0.75 | 9.6 | 64.8 | 150 |
| FIC 120 H 12G0.75 | 12G0.75 | 10.1 | 86.4 | 186 |
| FIC 120 H 18G0.75 | 18G0.75 | 12 | 129.6 | 265 |
| FIC 120 H 25G0.75 | 25G0.75 | 14.1 | 180 | 365 |
| FIC 120 H 2×1.0 | 2×1.0 | 5.8 | 19.2 | 59 |
| FIC 120 H 3G1.0 | 3G1.0 | 6.1 | 28.8 | 72 |
| FIC 120 H 3×1.0 | 3×1.0 | 6.1 | 28.8 | 72 |
| FIC 120 H 4G1.0 | 4G1.0 | 6.6 | 38.4 | 87 |
| FIC 120 H 4×1.0 | 4×1.0 | 6.6 | 38.4 | 87 |
| FIC 120 H 5G1.0 | 5G1.0 | 7.3 | 48 | 104 |
| FIC 120 H 7G1.0 | 7G1.0 | 8.1 | 67.2 | 138 |
| FIC 120 H 8G1.0 | 8G1.0 | 9.7 | 76.8 | 164 |
| FIC 120 H 12G1.0 | 12G1.0 | 10.7 | 115.2 | 225 |
| FIC 120 H 14G1.0 | 14G1.0 | 11.4 | 134.4 | 261 |
| FIC 120 H 18G1.0 | 18G1.0 | 12.9 | 172.8 | 328 |
| FIC 120 H 25G1.0 | 25G1.0 | 15 | 240 | 445 |
| FIC 120 H 41G1.0 | 41G1.0 | 19.2 | 393.6 | 719 |
| FIC 120 H 2×1.5 | 2×1.5 | 6.4 | 28.8 | 76 |
| FIC 120 H 3G1.5 | 3G1.5 | 6.8 | 43.2 | 94 |
| FIC 120 H 3×1.5 | 3×1.5 | 6.8 | 43.2 | 94 |
| FIC 120 H 4G1.5 | 4G1.5 | 7.4 | 57.6 | 115 |
| FIC 120 H 5G1.5 | 5G1.5 | 8.3 | 72 | 142 |
| FIC 120 H 7G1.5 | 7G1.5 | 9 | 100.8 | 184 |
| FIC 120 H 8G1.5 | 8G1.5 | 10.8 | 115.2 | 218 |
| FIC 120 H 9G1.5 | 9G1.5 | 11.6 | 129.6 | 245 |
| FIC 120 H 12G1.5 | 12G1.5 | 12.2 | 172.8 | 308 |
| FIC 120 H 14G1.5 | 14G1.5 | 13 | 201.6 | 357 |
| FIC 120 H 18G1.5 | 18G1.5 | 14.6 | 259.2 | 449 |
| FIC 120 H 25G1.5 | 25G1.5 | 17.2 | 360 | 617 |
| FIC 120 H 34G1.5 | 34G1.5 | 19.8 | 489.6 | 821 |
| FIC 120 H 2×2.5 | 2×2.5 | 7.6 | 48 | 113 |
| FIC 120 H 3G2.5 | 3G2.5 | 8.3 | 72 | 146 |
| FIC 120 H 4G2.5 | 4G2.5 | 9 | 96 | 180 |
| FIC 120 H 5G2.5 | 5G2.5 | 10.1 | 120 | 221 |
| FIC 120 H 7G2.5 | 7G2.5 | 11.2 | 168 | 295 |
| FIC 120 H 12G2.5 | 12G2.5 | 15.1 | 288 | 491 |
| FIC 120 H 4G4.0 | 4G4.0 | 10.8 | 153.6 | 268 |
| FIC 120 H 5G4.0 | 5G4.0 | 12.1 | 192 | 328 |
| FIC 120 H 7G4.0 | 7G4.0 | 13.4 | 268.8 | 438 |
| FIC 120 H 4G6.0 | 4G6.0 | 13 | 230.4 | 391 |
| FIC 120 H 5G6.0 | 5G6.0 | 14.5 | 288 | 478 |
| FIC 120 H 7G6.0 | 7G6.0 | 16 | 403.2 | 638 |
| FIC 120 H 4G10.0 | 4G10.0 | 16.2 | 384 | 635 |
| FIC 120 H 5G10.0 | 5G10.0 | 18.1 | 480 | 775 |
| FIC 120 H 4G16.0 | 4G16.0 | 18.8 | 614.4 | 930 |
| FIC 120 H 5G16.0 | 5G16.0 | 21.2 | 768 | 1147 |
| FIC 120 H 4G25.0 | 4G25.0 | 23.5 | 960 | 1442 |
| FIC 120 H 5G25.0 | 5G25.0 | 26.4 | 1200 | 1773 |
| FIC 120 H 4G35.0 | 4G35.0 | 26.6 | 1344 | 1917 |
